Discontinued
Ericsson Cradlepoint E100
Micro 5G, SD-WAN, and security appliance for US/CDA hybrid WAN sites
Ericsson NetCloud Manager allows you to accomplish more, faster, and with fewer resources. It’s an intuitive, easy-to-use cloud management and orchestration platform designed to simplify the configuration, deployment, operation, and troubleshooting of far-flung wireless routers. With browser and mobile application access, Ericsson NetCloud Manager enables effective management — from anywhere!
 |
Category | Small Branch |
 |
Cloud management | Yes |
 |
Wireless connectivity | 5G NR & Cat 19 LTE or Cat 7 LTE |
 |
5G status | 5G embedded |
 |
Form factor | Industrial Plastic |
 |
Ethernet ports | 5 x GbE |
 |
USB ports | 1 |
 |
Serial ports | 0 |
 |
Dual-modem support | No |
 |
Network operator standards | PTCRB (U.S. & Canada) |
 |
Network operator certifications | AT&T, T-Mobile, Verizon |
 |
Regions | Varies by modem |
 |
Throughput | 850 Mbps (Firewall) |
 |
VPN tunnel count | 20 |
 |
Wi-Fi | Dual-band, dual-concurrent; 802.11ac (Wi-Fi 5) |
 |
GNSS | Passive |
 |
PoE | No |
 |
Operating temperature | 0 °C to 40 °C (32 °F to 104 °F) |
 |
Rack mountable | No |
 |
Private cellular network | Yes — CBRS, 4G LTE, 5G |
 |
Battery option | Yes |
Software feature availability depends on the service plan selected. Learn more about the Ericsson NetCloud packages.
View a brief overview of this device, including what's inside the box and basic setup and installation instructions.
View a brief overview of this device, including what's inside the box and basic setup and installation instructions.
View the technical specifications for this device, including accessories and warranty information.
